THERMOPLASTICS / PHENOPLASTICS

Thermoplastics are plastics than can be deformed above a defined temperature. They can be further subdivided on the basis of their thermal, chemical or mechanical characteristics.

In the thermoplastics field we offer doctor blades with and without fabric inlay. The fabric inlay provides improved characteristics such as higher strength combined with better cleaning effects. Nevertheless, the cleaning effect on the roll and cylinder surface remains gentle.

Our experienced service technicians can assist you with the selection of the right blades for your particular application.

DURADA®-DT

Doctor Blade from advanced polymer material

MATERIAL
Multi-layer fiberglass fabric structure with thermoplastic polymer matrix and ceramic coating at tip, very wear-resistant
ADVANTAGES
MATERIAL COLOUR
beige
LOGO COLOUR
black
BENDING STRENGTH
up to 250 N/mm²
TEMPERATURE RESISTANCE IN CONTINUOUS USE
180°C
CHEMICAL RESISTANCE
very good
WATER ABSORPTION none
STANDARD DIMENSIONS*
THICKNESS mm (inch)
WIDTH mm (inch)
1.5 (0.060) 75 (3)
* OTHER WIDTHS AND THICKNESSES AVAILABLE ON REQUEST
KEY FEATURES
CONTINUOUS LENGTH TO INDIVIDUAL SPECIFICATION
DOUBLE BEVEL
Bevel Angle 20°
Without rebate; groove to customer requirements
Wear indicator: Ceramic layer is an indicator
RIVETING
Ready to use for all standard holder systems with appropriate rivets.
Productflyer
