Carbon fibres exhibit very good electrical and thermal conductance. The fibres are very strong and stiff whilst simultaneously having a low breaking elongation.
The doctor blades that we manufacture exclusively from carbon fibre fabric also have a very good cleaning effect. They were developed for areas with high levels of mechanical loading.
Our experienced service technicians can assist you with the selection of the right blades for your particular application.
CLOUTH VERTURA®-100S
Doctor Blade from advanced composite material
| MATERIAL | |
|---|---|
| Carbon fibre fabric with a specially designed epoxy-resin System, extremely low coefficient of friction, extremely wear-resistant, very good cleaning effect. |
| ADVANTAGES | |
|---|---|
|
MATERIAL COLOUR |
grey |
|
LOGO COLOUR |
black |
|
BENDING STRENGTH |
up to 800 N/mm² |
|
TEMPERATURE RESISTANCE (TG) |
185°C |
|
CHEMICAL RESISTANCE |
very good |
| WATER ABSORPTION | none |
| STANDARD DIMENSIONS* | |
|---|---|
|
THICKNESS mm (inch) |
WIDTH mm (inch) |
|
1.5 (0.060) |
50 (2), 75 (3) |
| 1.9 (0.075) | 50 (2), 75 (3) |
| * Other widths and thicknesses available on request | |
| KEY FEATURES | |
|---|---|
|
Continuous length to individual specification |
|
|
Single or double bevel |
|
|
Bevel 20° |
|
|
Rebate or groove |
|
| Printed wear indicators |
| RIVETING | |
|---|---|
| Ready to use for all standard holder systems with appropriate rivets. | |
CLOUTH VERTURA®-100S
